Beside a Giant

Saturn's largest moon, Titan, looks small here, pictured to the right of the gas giant in this Cassini spacecraft view.
PIA NumberPIA14597
Language
  • english

Saturn's largest moon, Titan, looks small here, pictured to the right of the gas giant in this Cassini spacecraft view.

Titan (3,200 miles, or 5,150 kilometers across) is in the upper right. Saturn's rings appear across the top of the image, and they cast a series of shadows onto the planet across the middle of the image.

The moon Prometheus (53 miles, or 86 kilometers across) appears as a tiny white speck above the rings in the far upper right of the image. The shadow cast by Prometheus can be seen as a small black speck on the planet on the far left of the image, between the shadows cast by the main rings and the thin F ring. The shadow of the moon Pandora also can be seen on the planet south of the shadows of all the rings, below the center of the image towards the right side of the planet. Pandora is not shown here.

This view looks toward the southern, unilluminated side of the rings from about 1 degree below the ringplane.

The image was taken with the Cassini spacecraft wide-angle camera on Jan. 5, 2012 using a spectral filter sensitive to wavelengths of near-infrared light centered at 752 nanometers. The view was acquired at a distance of approximately 426,000 miles (685,000 kilometers) from Saturn and at a Sun-Saturn-spacecraft, or phase, angle of 20 degrees. Image scale is 23 miles (37 kilometers) per pixel on Saturn.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, D.C. The Cassini orbiter and its two onboard cameras were designed, developed and assembled at JPL. The imaging operations center is based at the Space Science Institute in Boulder, Colo.

For more information about the Cassini-Huygens mission visit http://saturn.jpl.nasa.gov . The Cassini imaging team homepage is at http://ciclops.org .

Credit: NASA/JPL-Caltech/Space Science Institute
